Output Specification
Output Capacity (KVA ) – 1 KVA
Output Capacity (KW ) – 0.8 KW
Output Power Factor – 0.8 Power Factor
Output Phase – 1 Phase
Output Voltage – 230 Volt
Output Waveform type – Sine Wave
Output Connections – Indian Socket
General Specifications
Flexible Battery Option – No
Isolation Transformer – Optional
Paralleling Options – Not Available
Rack Mounting Kit – Not Available
Paralleling Kit for Synchronising
Input Specification
Input Voltage – 230 Volt
Input Phase – 1 Phase
Input frequency – 50/60Hz +/- 3 Hz
Input Voltage Range (Output Derated) – 110 – 300 Volt
Input voltage range for main operations – 160 – 280 Volt
Input frequency Range – 40 – 70 Hz
Input Connections – 3-Pin 6A Indian Socket
Batteries & Runtime
Battery DC Bus – 36 – VDC
Maximum Charger Capacity -1 Amp.
Battery Position Option -Internal
Internal Battery Capacity (VAH) – 252 VAH
Battery Type Compatibility – SMF Battery
Communication & Management
SNMP Management – Optional
Physical
Maximum Height – 220 Mm
Maximum Width – 145 Mm
Maximum Depth – 397 Mm
Net Weight – 13 Kg
Colour – Black
Environmental
Operating Temperature – 0 – 40 °C
Operating Relative Humidity – 0 – 95 % Rh
Other Specifications
Technology – Double Conversion Online
