Output Specification
Output Capacity (KVA ) – 1 Kva
Output Capacity (KW ) – 0.8 Kw
Output Power Factor – 0.8 Power Factor
Output Phase – 1 Phase
Output Voltage – 230 Volt
Other Output Voltage – 220 Or 240 Volt
Efficiency at Full Load – >90 %
Output Voltage Distortion – <2 %
Output Frequency (sync to mains) – 50/60Hz +/- 3 Hz
Output Frequency (not synced) – 60Hz +/- 0.1% for 60Hz nominal, 50Hz +/- 0.1% for 50Hz nominal
Load Crest Factor – 3:1
Output Voltage THD – <3 %
Transfer Time – <0 Ms
Output Waveform type – Sine Wave
Output Connections – 3 Pin Indian Socket (04 Nos.)
Bypass – Internal Bypass (automatic & manual)
UPS Parallel Upto – No
Overload Capacity – 150% for 1 minute 125% for 10 minutes
General Specifications
Flexible Battery Option – No
Isolation Transformer – Optional
Paralleling Options – Not Available
Rack Mounting Kit – Not Available
Paralleling Kit for Synchronising – Not Available
Input Specification
Input Voltage – 230 Volt
Other Input Voltage – 220 Or 240 Volt
Input Phase – 1 Phase
Input frequency – 50/60Hz +/- 3 Hz
Input Voltage Range (Output Derated) – 110 – 280 Volt
Input voltage range for main operations – 175 – 280 Volt
Input frequency Range – 40 – 70 Hz
Input Power Factor – > 0.98
Input Connections – 3-Pin 6A Indian Socket
Input Protection
Thermal Circuit Breaker
Batteries & Runtime
Approved Battery Capacity (AH)- 7 – 150 Amp.
Battery DC Bus – 24 – Vdc
Maximum Charger Capacity – 12 Amp.
Battery Position Option – External
Battery Type Compatibility
SMF / Flooded Batteries
Batteries Recharge Time upto 90%
<10 Hrs.
Communication & Management
Control panel
Multi-function LCD status and control console
SNMP Management
Optional
Power Management Software
In-Built
Interface Port(s)
DB-9 RS-232, Smart-Slot
Audible Alarm
Audible and visible alarms prioritized by severity
Audible noise at 1 meter from surface of unit
< 55 Decibal
Physical
Maximum Height
220 Mm
Maximum Width
400 Mm
Maximum Depth
397 Mm
Shipping Height
340 Mm
Shipping Width
235 Mm
Shipping Depth
478 Mm
Net Weight
5.7 Kg
Shipping weight
6.3 Kg
Colour
Black
Environmental
Operating Temperature
0 – °C 40
Operating Relative Humidity
0 – 95 % Rh
Operating Elevation
0 – 914 Meters
Storage Temperature
-20 – +60 °C
Storage Relative Humidity
0 – 95 % Rh
Storage Elevation
0 – 4572 Meters
Compliances
Compliance
IS 16242 (Part1): 2014
Approvals
CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE
Other Environmental Compliance
Compliant
Other Specifications
Technology
Double Conversion Online
Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Surge Protection
Yes
